Features
Large entrance pupil with diffraction-limited imaging performance
Coaxial telecentric illumination with large exit pupil diameter
Compact and rigid mechanical structure
Compatible with dual-camera and auto-focus modules
Customizable upon request
External Dimensions (mm)
Specifications
| Parameter | VMU-100-16D | VMU-100-16S | VMU-200-33S |
| Model | VMU-100-16D | VMU-100-16S | VMU-200-33S |
| Tube Lens Focal Length | 100mm | 100mm | 200mm |
| Magnification | 0.5X | 0.5X | 1.0X |
| Image Circle | Ø16mm | Ø16mm | Ø33mm |
| Camera Mount | Dual C-Mount | Single C-Mount | F/M58-Mount |
| Wavelength Range | 430nm~670nm | 430nm~670nm | 430nm~670nm |
| Weight | 809g | 779g | TBD |
| Parfocal Distance2 | 37.9mm | 37.9mm | 37.9mm |
